MECA 705S-9.200, SMA-F, 6-12.4 GHz Directional Coupler) Directional Coupler)

Description:
MECA’s 705S-9.200 3 dB 90° hybrid coupler features a frequency range of 6.000 - 12.400 GHz, power rating of 50 watts (3K watts peak). These units are equipped with N-Female connectors and a rugged aluminum housing coated with a clear iridite finish for long lasting, reliable performance. Made in USA and offer low insertion loss and excellent VSWR. Whether you are designing a duplexer, combining amplifiers or just need a 90° phase shift with high isolation to avoid mixing signals, then MECA’s 705 series will help you achieve your objectives.

Notes:
1. Couplig loss includes insertion loss and frequency sensitivity.
2. 50 ohm nominal impedance standard.
3. Operating temperature range is -55°C to +85°C.
